Reverse Proxy in Backend Engineering

Every production backend system has one thing between the internet and the application server: a reverse proxy. You deploy your FastAPI app on port 8000, your Go service on 8080, your Redis dashboard somewhere else — and none of them are directly exposed. A reverse proxy handles all incoming traffic and decides where it goes.

This article breaks down what a reverse proxy is, how it differs from a forward proxy, and the patterns you’ll actually use in production.

Forward Proxy vs Reverse Proxy

These two terms get mixed up constantly. The difference is about who it acts on behalf of.

Forward proxy — acts on behalf of the client. The client knows about the proxy; the server does not.

Client → Forward Proxy → Internet → Server

Use cases: corporate firewalls, anonymising clients, bypassing geo-restrictions.

Reverse proxy — acts on behalf of the server. The client knows nothing about the backend; it only talks to the proxy.

Client → Reverse Proxy → Server(s)

Use cases: hiding backend topology, SSL termination, load balancing, caching, rate limiting.

In backend engineering, when you say “proxy” you almost always mean the reverse kind.

What a Reverse Proxy Actually Does

When a request hits your reverse proxy, it can:

1. Terminate SSL — decrypt the HTTPS request so your app only handles plain HTTP internally
2. Route by path or host — send /api/* to the API service, /static/* to a CDN or object store
3. Load balance — distribute requests across multiple instances of the same service
4. Cache responses — serve repeated requests without hitting the app at all
5. Compress — gzip/brotli responses before sending to the client
6. Rate limit — drop or queue traffic above a threshold
7. Add/strip headers — inject X-Forwarded-For, X-Request-ID, remove internal headers before responding

Each of these would require individual middleware in every service. A reverse proxy centralises them.

Nginx: The Most Common Setup

Nginx is still the default choice for most teams. Here’s a minimal but realistic config for a Python/Go backend:

# /etc/nginx/sites-available/myapp

upstream api_backend {
    server 127.0.0.1:8000;  # FastAPI / Django
    server 127.0.0.1:8001;  # second instance
    keepalive 32;            # reuse connections
}

server {
    listen 80;
    server_name api.example.com;
    return 301 https://$host$request_uri;
}

server {
    listen 443 ssl http2;
    server_name api.example.com;

    ssl_certificate     /etc/letsencrypt/live/api.example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/api.example.com/privkey.pem;

    # Security headers
    add_header X-Content-Type-Options nosniff;
    add_header X-Frame-Options DENY;

    # Proxy to app
    location /api/ {
        proxy_pass         http://api_backend;
        proxy_set_header   Host              $host;
        proxy_set_header   X-Real-IP         $remote_addr;
        proxy_set_header   X-Forwarded-For   $proxy_add_x_forwarded_for;
        proxy_set_header   X-Forwarded-Proto $scheme;
        proxy_read_timeout 30s;
    }

    # Serve static files directly — don't hit the app at all
    location /static/ {
        alias /var/www/myapp/static/;
        expires 30d;
        add_header Cache-Control "public, immutable";
    }
}

Two things worth noting:

• upstream with multiple servers gives you round-robin load balancing with zero extra config
• keepalive 32 reuses connections to the backend — critical for high-throughput services

Path-Based Routing Across Multiple Services

Microservices need path-based (or host-based) routing. Nginx handles this cleanly:

server {
    listen 443 ssl;
    server_name example.com;

    # Auth service (Go, port 9001)
    location /auth/ {
        proxy_pass http://127.0.0.1:9001/;
    }

    # ML inference service (Python, port 9002)
    location /predict/ {
        proxy_pass          http://127.0.0.1:9002/;
        proxy_read_timeout  120s;   # ML models can be slow
    }

    # Frontend (Node, port 3000)
    location / {
        proxy_pass http://127.0.0.1:3000;
    }
}

Note the trailing slash on proxy_pass — proxy_pass http://host:port/ strips the location prefix before forwarding. proxy_pass http://host:port keeps it. This is a silent gotcha that breaks routing in subtle ways.

Traefik: Proxy-as-Config for Docker

If you work with Docker or Kubernetes, Traefik auto-discovers your services via labels without touching a config file.

# docker-compose.yml

services:
  api:
    image: myapp:latest
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.api.rule=Host(`api.example.com`) && PathPrefix(`/api`)"
      - "traefik.http.routers.api.entrypoints=websecure"
      - "traefik.http.routers.api.tls.certresolver=letsencrypt"
      - "traefik.http.services.api.loadbalancer.server.port=8000"

  traefik:
    image: traefik:v3.0
    command:
      - "--providers.docker=true"
      - "--entrypoints.websecure.address=:443"
      - "--certificatesresolvers.letsencrypt.acme.email=you@example.com"
    ports:
      - "443:443"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock

Spin up a new service, add labels, and Traefik picks it up live — no reload. This is why it dominates Docker-based stacks.

The X-Forwarded-For Problem

When your app sits behind a reverse proxy, request.client.host always returns the proxy’s IP, not the real client IP. You need to read X-Forwarded-For.

In FastAPI:

from fastapi import FastAPI, Request

app = FastAPI()

@app.get("/ip")
def get_ip(request: Request):
    # X-Forwarded-For can be a comma-separated chain of proxies
    forwarded_for = request.headers.get("X-Forwarded-For")
    if forwarded_for:
        client_ip = forwarded_for.split(",")[0].strip()
    else:
        client_ip = request.client.host
    return {"ip": client_ip}

In Go (using net/http):

func realIP(r *http.Request) string {
    if xff := r.Header.Get("X-Forwarded-For"); xff != "" {
        ips := strings.Split(xff, ",")
        return strings.TrimSpace(ips[0])
    }
    ip, _, _ := net.SplitHostPort(r.RemoteAddr)
    return ip
}

Security note: X-Forwarded-For is client-controlled. A client can spoof it. Only trust it when your proxy explicitly sets it and strips any client-supplied version. In Nginx, proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for appends — use $remote_addr only if you want a clean replacement.

Rate Limiting at the Proxy Level

Doing rate limiting in your application code is wasteful — the request already consumed CPU and connections before being rejected. Do it at the proxy.

Nginx rate limiting:

# Define a zone: 10MB memory, keyed by IP, 10 req/sec limit
limit_req_zone $binary_remote_addr zone=api_limit:10m rate=10r/s;

server {
    location /api/ {
        # Allow burst of 20 requests, then queue (no delay) up to rate
        limit_req zone=api_limit burst=20 nodelay;
        limit_req_status 429;

        proxy_pass http://api_backend;
    }
}

This handles the token bucket algorithm for you. 429 responses are returned before your app code even runs.

WebSocket Proxying

WebSockets need special handling because they upgrade the HTTP connection and hold it open. The default proxy config drops them.

location /ws/ {
    proxy_pass          http://127.0.0.1:8000;
    proxy_http_version  1.1;
    proxy_set_header    Upgrade    $http_upgrade;
    proxy_set_header    Connection "upgrade";
    proxy_set_header    Host       $host;
    proxy_read_timeout  3600s;   # hold open for an hour if needed
}

The Upgrade and Connection headers are required. Without proxy_http_version 1.1, Nginx defaults to HTTP/1.0 which doesn’t support the upgrade mechanism.

Health Checks and Passive Failure Detection

Nginx Plus has active health checks; in open-source Nginx you rely on passive detection — if a backend returns errors, it gets temporarily removed.

upstream api_backend {
    server 127.0.0.1:8000 max_fails=3 fail_timeout=30s;
    server 127.0.0.1:8001 max_fails=3 fail_timeout=30s;
}

After 3 failures within 30 seconds, that server is marked down for 30 seconds. Combined with your application’s own /health endpoint, this gives you automatic failover without an orchestrator.

Quick Reference: Header Cheat Sheet

Wrapping Up

A reverse proxy is not an optional add-on — it’s the front door of every serious backend. The logic it centralises (SSL, routing, rate limiting, compression, header injection) would otherwise be duplicated across every service you write.

For most setups:

• Single server, single app → Nginx is all you need
• Docker Compose → Traefik with labels is far less friction
• Kubernetes → Nginx Ingress Controller or Traefik Ingress
• High-scale / service mesh → Envoy or Caddy with plugins

The pattern is always the same: let the proxy handle the cross-cutting concerns, keep your application code focused on business logic.
